Family Pet Crematory with Movable system & & & & Auto. Door & & Independent Placement


Incinerator Model A1500, Intro

This design is big-scale pet cremation tools for huge pets.

Construction is dual/double combustion chamber with 03 units oil/gas burner,
batch load incineration equipment. Animal feed chamber is 1500Liters (Model: A1500).
Primary & Secondary combustion chambers and included mix-combustion chamber,
smoke filter chamber with firebrick and Refractory Concrete chamber. Batch load on
the bottom of chamber. Incinerator panel control suit for local operation.

Model

A1500

Burning Rate

Average 50 kgs/hour

Feed Capability

Ordinary 150 kgs

Key Combustion Chamber

1500 Liters

Extra Burning Chamber

500 Litres

Mix Combustion Chamber

Yes

Smoke Filter Chamber

Yes

Feed Setting

Hand-operated

Voltage

220V/380V

Gas Kind

Diesel Oil/ All-natural Gas/LPG

Heater

Italy Original

Oil Consumption (Diesel Oil)

Normal 34 kg/hour

Gas Consumption (Gas)

Common 41 m3n/hour

Inner Measurements

150 x 100 x 96cm (key chamber)

Outdoors Measurements

240 x 170 x 380cm (without chimney)

Temperature Monitor

Yes

Oil Container Capability( if oil gas)

300 Litres

Door Opening

59 x 81cm

Smokeshaft Length

10.0 Meters

Smokeshaft Type

Stainless-steel

Tools Gross Weight

7500 kgs

Operation Technical Specifications

Main Chamber Temperature

800 ℃–– – – -1000 ℃

Second Chamber Temperature Level

1000 ℃ -1200 ℃

Residency Time

2.0 Sec.

Burning Efficiency

> 98%

Waste Lower Calorific Power

3000Kcal
