Waste Incineration Therapy BURNING PRICE: 100-150kgs per hr HICLOVER TS150

BURNING RATE: -100 -150 kgs per hour

MINIMUM OPERATING TEMPERATURE: 800-1000 oC (PRIMARY BURNING)

MAX OPERATING TEMPERATURE LEVEL: 1000-1200 oC (AFTER HEATER BURNING)

SECONDARY MELTING CAPABILITY: COMPULSORY

DENSITY INSULATION: 50 mm high

Refractory capability: minutes 114mm

STURDY REFRACTING LINING TO WITHSATND 17500C

AVEARGE BURN OUT TIME: MAXIMUM 3HRS

GAS TYPE: FUEL OIL (DIESEL)

FUEL INTAKE IN LTRS/HR: average 14

RESIDNECY TIME IN SECONDARY CHAMBER: 2 PHASES

Items/Model

TS150( PLC)


Concept

Waste Incineration Treatment

Burn Price

Standard 100-150 kg/hour

Feed Capability

Standard 750kg/feeding

Control Setting

PLC( Programmable Reasoning Controller Incinerator)

Chamber Material

High Alumina Fire Brick Wall, 1750 ℃ Rate

Paint for outdoors face

800 ° C Price

Burning Chamber

1570L

Inner Dimensions

150x100x105cm

Secondary Chamber

750L

Smoke Filter Chamber

Yes

Feed Mode

Guidebook

Voltage

210/230V 50/60Hz

Power

0.9 Kw

Oil Consumption (Liter/hour)

Ordinary 14( D.O)

Gas Intake (m3/hour)

***

Temperature Screen

Digital Show

Temperature Level Defense

Yes

Oil Tank

2000L

Feed Door

80x60cm

Chimney

10Meter

Smokeshaft Kind

Stainless Steel

1st. Chamber Temperature

800 ℃–– -1000 ℃

second. Chamber Temperature Level

1000 ℃ -1200 ℃

Residency Time

2.0 Sec.

Gross Weight

8500kg

Exterior Dimensions

300x160x280cm( without chimney)
