Large General waste incinerator Burn Rate up to 250kg per hour

Items/Model	TS300(PLC)
Principle	Waste Incineration Treatment
Burn Rate	Average 250 kg/hour
Control Mode	PLC(Programmable Logic Controller Incinerator)
Combustion Chamber	2000L
Internal Dimensions	170x120x100cm
Secondary Chamber	1000L
Smoke Filter Chamber	Yes
Feed Mode	Manual
Voltage	220V
Power	2.5Kw
Oil Consumption (kg/hour)	Average 28(DO)
Gas Consumption (m3/hour)	***
Temperature Monitor	Digital Display
Temperature Protection	Yes
Oil Tank	1000L
Feed Door	80x60cm
Chimney	10Meter
Chimney Type	Stainless Steel
1st. Chamber Temperature	800℃–-1000℃
2nd. Chamber Temperature	1000℃-1200℃
Residency Time	2.0 Sec.
Gross Weight	11000kg
External Dimensions	400x210x300cm(without chimney)
