Item Specification Model YD-30C (customer made model) Main Product List Primary Combustion Chamber(Main body stainless steel) Secondary Combustion Chamber(Main body stainless steel) Mix-Combustion Chamber Wet Scrubber( Washing Tower)(Main body stainless steel) Incinerator Control Case Chimney:5.0Meters *(upgrade to Stainless Steel, free cost) Italy gas burner: 02 units Oil Tank (if oil fuel): 100Liters Model YD-30C Feed […]
Model A1500 (customer made model) Internal Dimensions 150 x 100 x 96cm Suit for Animal Cat – yes Dog – yes Pig – yes Cow – no Main Product List Primary Combustion Chamber Secondary Combustion Chamber Mix-Combustion Chamber Wet Scrubber( Washing Tower)(Optional Part) Incinerator Control Case Chimney:10.0Meters *(upgrade to Stainless Steel, free cost) Italy oil […]
• A burn rate of 25 – 30kg/hr. • Consists of two chambers to ensure significant reduction of emissions and be capable of temperatures in the range of 800-1000˚c. • Incinerator must be of a low maintenance design, be diesel fuelled and need no more than 15 amp 220-250 V power. KW consumption per hour […]
Main Product List Primary Combustion Chamber Secondary Combustion Chamber Mix-Combustion Chamber Smoke Filter Chamber Incinerator Control Case Chimney:5.0Meters *(upgrade to Stainless Steel, free cost) Italy oil burner: 02 sets Oil Tank: 150Liters Mobile Trailer for Incinerator Model YD-50C Burning Rate (kgs/Hour) Average 20-50 kgs/hour Feed Capacity (kgs) Average 80 kgs/feeding Equipment Weight 2500 kgs(Incinerator) Primary […]
PRIMARY CHAMBER Heavy-duty steel casing High quality refractory lining and insulation Large full size top load counterbalanced door 1 x oil/gas fired ignition burners operated on/off SECONDARY CHAMBER Heavy-duty steel casing High quality refractory lining and insulation 2 second gas residence time 1 x oil/gas fired ignition burners operated on/off CHIMNEY Heavy-duty stainless steel casing […]
We finish this project in year 2010 to 2011 and delivery to Hochiminh port, Vietnam with 1×40’feet open top full container. Items/Model YD-500 Burning Rate (kgs/Hour) 500 kgs/Hr. Feed Capacity (kgs) 800 kgs Equipment Weight 13000 kgs Primary Chamber (Liters) 4000 Secondary Chamber (Liters) 1500 External Dimensions (cm) 320x220x460 Internal Dimensions (cm) 257x147x108 Oil Tank(Liters) […]
Primary and secondary burners: Separate electrically spark-ignited primary burners and secondary burners with automatic control shall be used to achieve the specified temperature requirements in the primary and secondary chambers. The flames of the primary and secondary burners shall not impinge on the incinerator walls or floor. The primary combustion chamber must: 1. Be accepted […]
There are 03 sets Model YD-100 delivery to Iraq between year 2013 to 2014. The incinerator use for local several construction sites and all fuel type is diesel oil. Items/Model YD-100 Burning Rate (kgs/Hour) 100 kgs/Hr. Feed Capacity (kgs) 200 kgs Equipment Weight 5300 kgs Primary Chamber (Liters) 1200 Secondary Chamber (Liters) 500 External […]
Incinerator Model YD-30 for Australia Melbourne customer. From year 2011 to 2013, we delivery 02 different model for this customer, one is model SYC-50 (now updated to Model TS50 PLC) and one model YD-30. Both two model is gas fuel type and these incinerator for local family pet cremation business. Items/Model YD-30 Burning Rate (kgs/Hour) […]
Types of incinerator design acceptable: Dual-chamber controlled air incinerator or dual- chamber pyrolytic incinerator Materials of construction: The incinerator shall not have any asbestos, asbestos-containing substances, mercury thermometers, and mercury switches. Refractory materials shall be able to meet relevant standards under ISO TC33 and CEN/TC 187.Waste feed system into the combustion chamber batch or continuous […]
